| Frame & Geometry |
| Frame |
Hi-ten steel, standard head tube, mid bottom bracket, top tube gusset |
| Top Tube Length |
18" |
| Head Tube Angle |
74.5° |
| Seat Tube Angle |
71° |
| Chainstay Length |
12.8" |
| Bottom Bracket Height |
10.5" |
| Standover Height |
8" |
| Fork & Headset |
| Fork |
Hi-ten steel, 2-piece steerer, tapered legs |
| Headset |
Standard 1-1/8" |
| Handlebar & Stem |
| Bars |
Hi-ten steel, rise 7.25" |
| Stem |
Verde top load, 50 mm reach |
| Brakes |
| Brake Type |
Alloy U-brake |
| Hubs & Drivetrain |
| Front Hub |
Sealed bearing alloy, 3/8" axle |
| Rear Hub |
Fully sealed, alloy, 14 mm axle, 9-tooth driver |
| Sprocket |
Verde Recon, 25T chromoly |
| Cranks |
3-piece tubular chromoly, 152 mm |
| Bottom Bracket |
19 mm sealed mid |
| Chain |
Taya 410, black |
| Pedals |
Nylon composite platform |
| Wheels & Tyres |
| Rims |
6061 aluminum, single wall, 36 hole |
| Tires |
18 × 2.1" DUO SVS (front & rear) |
| Seat & Post |
| Seat |
Verde Hex, integrated post |
| Seatpost |
Alloy, integrated, 25.4 mm diameter, ~175 mm length |
| Seat Clamp |
Alloy, black |
| Grips |
DUO Homan Flange w/ press-in bar ends |
| Weight |
~ 20.2 lbs (˜ 9.16 kg) |
