| FRAMESET |
| Frame |
Orbea Terra Hydro disc, hydroformed triple butted aluminium, HS 1.5", PF, Thru Axle 12x142mm rear (M12x2 P1), DT internal cable routing, 27.2mm seat tube, MMS system. |
| Fork |
Orbea Terra ICR, full carbon, 1-1/8"–1.5" tapered head tube compatible, Thru Axle 12x100mm (M12x2 P1). |
| Steerer Tube |
FSA 1-1/2" Integrated Aluminium Cup |
| DRIVETRAIN |
| Crankset |
Shimano GRX RX610 30x46t |
| Shifters |
Shimano GRX RX610 |
| Cassette |
Shimano HG710 11-36t 12-Speed |
| Rear Derailleur |
Shimano GRX RX820 |
| Front Derailleur |
Shimano GRX RX820 |
| Chain |
Shimano M6100 |
| COCKPIT |
| Handlebar |
OC Gravel GR31-R, Rise 15, Reach 70, Drop 110 |
| Stem |
OC Road Performance RP22, -5º |
| BRAKES |
| Brakes |
Shimano RX400 Hydraulic Disc |
| Brakes Configuration |
N/A |
| WHEELS |
| Wheels |
Alloy, Tubeless, 700c, 21c |
| Tyres |
Vittoria Terreno Dry Gravel 700x38c |
| Front Wheel Axle |
Orbea Thru Axle 12x100mm M12x2 P1 Solid |
| Rear Wheel Axle |
Orbea Thru Axle 12x142mm M12x2 P1 Solid, inner threaded |
| COMPONENTS |
| Seatpost |
SP 0.2 Carbon, 27.2mm, Setback 20 |
| Saddle |
Prologo Akero AGX, black rails, size 155mm |
| ACCESSORIES |
| Mudguard |
— |
| Handlebar Tape |
Orbea EVA |
